Ubiquiti Pro XG Aggregation (USW-Pro-XG-Aggregation)

The Ubiquiti Pro XG Aggregation is a professional-grade, high-capacity 32-port Layer 3 aggregation switch engineered for enterprise core and data center environments. Featuring 25G SFP28 connectivity, advanced Layer 3 routing, and Etherlighting™ technology, it delivers exceptional performance, scalability, and visual port identification.

Designed for rack-mounted deployments, this 1U switch provides ultra-high switching capacity and robust redundancy options, making it ideal for backbone aggregation, high-density server connections, and large-scale UniFi environments.

Key Features

• 32 × 25G SFP28 ports (25G / 10G / 1G compatibility)
• Layer 3 routing with advanced switching capabilities
• 1.6 Tbps switching capacity
• 800 Gbps non-blocking throughput
• Etherlighting™ port illumination for visual identification
• DC power redundancy (USP RPS support)
• 1U rackmount design for 19" racks
• 1.3" touchscreen LCM display for on-device monitoring

Performance Specifications

Layer 3 Capabilities

• DHCP Server & DHCP Relay
• Inter-VLAN Routing
• Static Routing (IPv4)
• Advanced ACLs (IPv4 & MAC-based)
• Virtual Network Override

Layer 2 Features

• LACP Port Aggregation
• STP & RSTP
• IGMP Snooping & Advanced IGMP Configuration
• 802.1X Authentication
• Jumbo Frames Support
• Port Mirroring & Isolation
• Voice VLAN & LLDP-MED

Hardware & Power

• Max Power Consumption: 200W
• Power Input: 100–240V AC (internal PSU)
• Redundancy: USP RPS DC input
• Heat Dissipation: 457 BTU/hr
• Form Factor: 1U Rack Mount
• Weight: 7.1 kg (15.7 lbs)

Built for enterprise core switching and high-density aggregation scenarios, the USW-Pro-XG-Aggregation delivers extreme throughput, intelligent Layer 3 routing, and advanced management capabilities — making it an ideal backbone solution for demanding UniFi deployments.
